| Art. no.: |
FUAA10011 |
| Dimensions: |
(WxHxD) 193x233x45 mm |
| Active intrusion protection: |
With mechatronic components (jimmying attempt monitoring only in the active state) |
| Alarming: |
E-mail, VoIP (landline, cellular communication, VoIP client) and push notification |
| Number of control devices: |
3 |
| Number of users: |
2 |
| Number of remote controls: |
3 |
| Number of wireless zones: |
3 (up to 11 detectors) |
| Number of virtual IP zones: |
3 (for IP alarm module or PIR network cameras) |
| Display: |
Status LEDs |
| Outputs: |
1xrelay, 4xtransistor |
| Battery type: |
12 V, 1.2 Ah |
| Operation: |
Local: via Secvest Key, wireless remote control, wireless additional door lock; remote: online via web interface, iPhone/iPad app |
| Width: |
193 mm |
| Gross weight: |
2.56 kg |
| DSL monitoring: |
Yes |
| Duplex antenna technology: |
Yes |
| Event log: |
500 |
| Extensible (wireless): |
Yes (by 8 detectors with IP alarm module) |
| Remote configuration: |
Yes |
| Wireless alarm bandwidth: |
Narrow band |
| Radio frequency: |
868,66 MHz |
| Transmission power: |
10 |
| Housing material: |
ABS |
| Height: |
233 mm |
| Integrated siren: |
No |
| Communication/alarming: |
email |
| Length: |
45 mm |
| Power consumption: |
13,8 |
| Max. operating temperature: |
55 °C |
| Max. humidity: |
75 % |
| Max. run time on backup power: |
5 h |
| Max. receiving range (outdoors): |
100 m |
| Max. receiving range (building): |
30 m |
| Max. sending range (outdoors): |
100 m |
| Max. sending range (building): |
30 m |
| Min. operating temperature: |
0 °C |
| Modulation: |
FM FM / AM |
| Installation location: |
With surrounding conditions optimally adjusted for wireless performance |
| Net weight: |
0.76 kg |
| Power supply unit: |
External |
| Network protocols: |
TCP/IP, DHCP, SMTP, DNS, NTP, HTTP |
| Network access: |
RJ-45 Ethernet 10/100 Base-T |
| Backup power supply: |
Yes |
| Configuration: |
Via integrated seb-server |
| Tamper monitoring: |
Yes |
| Switching outputs: |
7 |
| IP protection class: |
34 |
| Fuse: |
Reverse polarity protection |
| Voltage monitoring: |
Yes |
| DC voltage supply: |
13.8 V |
| Language of instructions: |
12 V, 1.2 Ah |
| OSD language: |
DE, UK, FR, NL, DK |
| Packaging language: |
DE, UK, FR, NL, DK |
| Power consumption: |
1200 mA |
| Partitions/surveillance partitions: |
1 |
| Environmental class: |
II |
| Supported browsers: |
Safari 5, Mozilla Firefox 5, Google Chrome, Internet Explorer 9 |
| Encryption: |
Yes |
| Video verification: |
Optional with PIR network camera |
| Access protection: |
User name, password |
