| Art. no.: |
FU8006 |
| Dimensions: |
(WxHxD) 205x285x43 mm |
| Active intrusion protection: |
With mechatronic components (continuous monitoring) |
| Connections: |
230 V screw terminal, a/b + a1/b1 screw terminal, loudspeaker, microphone, USB |
| Number of users: |
50 |
| Number of wired zones: |
2 |
| Number of remote controls: |
20 |
| Number of wireless zones: |
48 |
| Display: |
Graphic display, status light |
| Outputs: |
2 relay outputs, 32 wireless switch outputs (optional) |
| Battery type: |
6 x 1.2V, 2000 mAH, rechargeable batteries NiMH type AA |
| Operation: |
Via Secvest key, wireless remote control, wireless additional door lock, local, proximity chip key, wireless key switch, and wireless control panels |
| Width: |
285 mm |
| Duplex antenna technology: |
Yes |
| Event log: |
250 |
| Extensible (hybrid): |
Yes |
| Remote configuration: |
Yes |
| Radio frequency: |
868,6625 MHz |
| Transmission power: |
10 |
| Housing material: |
ABS |
| Height: |
206 mm |
| Integrated siren: |
Yes (97dB @ 1m) |
| Communication/alarming: |
Integrated dialer for transmission of voice, protocols, and SMS messages |
| Length: |
43 mm |
| Power consumption: |
22 |
| Max. number of control panels: |
4 |
| Max. operating temperature: |
55 °C |
| Max. battery charging time: |
72 h |
| Max. humidity: |
75 % |
| Max. run time on backup power: |
12 h |
| Max. receiving range (outdoors): |
100 m |
| Max. receiving range (building): |
30 m |
| Max. sending range (outdoors): |
100 m |
| Max. sending range (building): |
30 m |
| Menu guidance: |
Voice-operated |
| Min. operating temperature: |
-10 °C |
| Modulation: |
FM FM / AM |
| Installation location: |
With optimally adjusted surrounding conditions for wireless performance |
| Net weight: |
1.06 kg |
| Power supply unit: |
Integrated |
| Backup power supply: |
Yes |
| Configuration: |
Software programming |
| Protocols: |
NSL: Fast Format, Contact ID, SIA; maintenance: Scancom, Scanfast, Tunstall |
| Tamper monitoring: |
Yes |
| Switching outputs: |
34 |
| Security level: |
2 |
| Fuse: |
T 400 mA 250V fuse |
| Voltage monitoring: |
Yes |
| AC voltage supply: |
230 V |
| Language of instructions: |
English, Danish, Italian |
| OSD language: |
English, Danish, Italian |
| Packaging language: |
English, Danish, Italian |
| Power consumption: |
100 mA |
| Partitions/surveillance partitions: |
4 |
| Environmental class: |
II |
| Encryption: |
Yes |
| Certifications: |
INCERT, VSÖ, F&P, NCP |
| Zone closure: |
Double end of line |
